Visual Materials
Big Creek, Florence Lake Dam - Looking up-stream Arches 52 & 53
You might also be interested in
Big Creek, Florence Lake Dam - Arch 53
Visual Materials
Big Creek, Florence Lake Dam - Arch 53 from an up-stream perspective during construction. This is a closer shot on the sluice gate.
photCL SCE 02 - 23098
Big Creek, Florence Lake Dam - River Section, Florence Lake Dam looking up
Visual Materials
Big Creek, Florence Lake Dam - River Section, Florence Lake Dam looking up-stream.
photCL SCE 02 - 12790
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Hand tamping earth backfill in haunch between Arches 52 & 53 with Thor-Cochise spader.
photCL SCE 02 - 24812
Big Creek, Florence Lake Dam - Guniting Arch #53
Visual Materials
Big Creek, Florence Lake Dam - Guniting Arch #53 - close-up.
photCL SCE 02 - 23353
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of river section looking N (downstream) from approximately the upstream face of Arch 53, showing heavy reinforcing at junction of Buttresses 53 & 54, with arches 52, 53, & 54 (highest portion of dam), interados form trusses and studding for lower lifts on Arch 54, and counterweighted placing chutes in position for concreting a lift in Buttress 54.
photCL SCE 02 - 12707
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Closer view, looking west across river section from near Buttress 56. (Excavation for Arches 50, 51, & 52 shown ready for forms. Placing of lift in Buttress 55 has just been completed. Chutes shown in position for placing in Buttress 53.
photCL SCE 02 - 12730
