Big Creek, Florence Lake Dam - Buttress form and built up trusses.
photCL SCE 02 - 12759
Big Creek, Florence Lake Dam - View from in front of Arches
Visual Materials
Big Creek, Florence Lake Dam - View from in front of Arches - showing details of arch and buttress construction near foundations, looking Northeast from near the upstream surface of Arch 13. [Shop-built panel-type buttress forms are shown on buttresses 13, 14, and 15. Variable span interados form trusses are shown being erected for Arch 15.]
photCL SCE 02 - 12617
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of river section looking N (downstream) from approximately the upstream face of Arch 53, showing heavy reinforcing at junction of Buttresses 53 & 54, with arches 52, 53, & 54 (highest portion of dam), interados form trusses and studding for lower lifts on Arch 54, and counterweighted placing chutes in position for concreting a lift in Buttress 54.
photCL SCE 02 - 12707
Big Creek, Florence Lake Dam - Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Florence Lake Dam - North side of buttress #38.
photCL SCE 02 - 22178
Big Creek, Florence Lake Dam - Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Florence Lake Dam - North side of buttress #38.
photCL SCE 02 - 22179
Big Creek, Florence Lake Dam - Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Florence Lake Dam - West side of buttress #52.
