Powerhouse 2a

Description: Powerhouse 2a - Looking towards the West Portal from a point below the outlet of the Shaver Tunnel along penstock 2a. Riveted pipe in this section.
Type: Visual Materials(Opens in new tab)
Date: 7/20/1928
Call number: photCL SCE 02 - 14900
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
