Passenger Accommodations S.S. City of Puebla

Description: The sheet shows plans for two full decks, not identified, and steerage on the City of Puebla; cabins are identified, as are crew quarters, mess room, hatches, etc. Hand drawn on vellum. "Passenger Accommodations S.S. City of Puebla"--title at top of sheet. "Scale 1/16 in = 1 foot"--scale given. "L.C."--intials in the right corner of the image. "Case No. 406s Sheet No. 5465s"--purple stamp, lower right corner, numbers in ms., in ink. "Union Iron Works, Ship Yard Dec 1887 Drawer no. L2, Job No. 1624"-- purple stamp, lower right corner, date and numbers in ms., in ink. "C. of Puebla"--in ms., in ink, below stamped information, lower right corner. Focus of item: City of Puebla.
Type: Visual Materials(Opens in new tab)
Date: 1887 December
Call number: priJHK 00148
Find out more: View in the Huntington Digital Library

Passenger Accomodations : S.S. City of Panama

Visual Materials

The sheet shows plans for two full decks, not identified, on the City of Panama; the deck plans show passenger accommodations, along with the dining saloon, social hall, smoking room and other amenities. Hand drawn on vellum; some color. Title at center of sheet. "3/32" = 1 foot"--scale given below title. "Union Iron Works, Shipyard, Dec 19, 1890, Drawer No. L2, Job No. S.S. City of Panama"--purple stamp, lower right corner, date an information in ms., in ink. "Case No. 406s Sheet No. 5458s"--purple stamp, lower right corner, numbers in ms., in ink. Focus of item: City of Panama (1873-1913).

priJHK 00914

S.S. City of Rio De Janeiro

Visual Materials

The sheet shows plans for the upper deck and main deck on the vessel;plans show passenger accommodations, along with the social hall, gents bath and water closet, smoking room and other amenities. Hand drawn on vellum. "S.S. City of Rio De Janeiro"--title at the top of the drawing. No scale given. "Case No. 406s Sheet No. 5451s"--purple stamp, lower right corner, numbers in ms., in ink. "Union Iron Works, Shipyard, 18 , Drawer No., Job No."--purple stamp, lower right corner, spaces for ms. entries are blank. Focus of item: City of Rio De Janeiro.

priJHK 00155

S.S. Peru: capacities of holds, bunkers, stores, etc

Visual Materials

"S.S. Peru: Capacities of Holds, Bunkers, Stores, Etc."--title at bottom of sheet. "1/6" = 1 foot"--scale given at the bottom of the drawing. Hand drawn on vellum. This sheet has four tables giving the capacities for storage of cargo, water, coal and the cubic feet of rooms; also drawn is a simplified profile of the Peru showing the cargo holds. "Union Iron Works, Shipyard, June 30, 1892, Drawer No., Job No."--purple stamp, lower right corner, date in ms., in ink. "Case No. 406s Sheet No. 5437s"--purple stamp, lower right corner, numbers in ms., in ink. The Peru operated for Pacific Mail between 1892 and 1919; built for PMSSCO by Union Iron Works in 1891-92; she was the second Pacific Mail vessel to carry this name. Focus of item: Peru (1892-1919).

priJHK 00143

Image not available

Passenger Accommodations S.S. City of Puebla

Visual Materials

Artists: L.C. Publishers: Union Iron Works (San Francisco) Companies: Union Iron Works (San Francisco)

priJHK 00148

Pacific Mail Steamship Co.'s Steamer "Barracouta"

Visual Materials

The sheet shows the ship's Dining room, Berths, and Women's Steerage.. Hand drawn on vellum. Title at the bottom of the drawing. "Case No. 406s Sheet No. 7183s"--purple stamp, lower right corner, numbers in ms., in ink. Stamp and the case number are similar as the one found on priJHK 00143, indicating the origin of the drawing is Union Iron Works Co., San Francisco. Focus of item: Barracouta.

priJHK 00913

P.M.S.S. Peru : passenger plan

Visual Materials

The sheet shows plans for two full decks, not identified, and steerage on the Peru; the deck plans show passenger accommodations, along with the dining saloon, social hall, smoking room and other amenities. Hand drawn on vellum; some color. "P.M.S.S. Peru. Passenger Plan"--title in the center of the drawing. "Scale 3/32 inch = one foot"--scale given. "Case No. 406s Sheet No. 5444s"--purple stamp, lower right corner, numbers in ms., in ink; stamp and the case number are the same as the one found on priJHK 00143, indicating the origin of the drawing is Union Iron Works Co., San Francisco. The Peru operated for Pacific Mail between 1892 and 1919; built for PMSSCO by Union Iron Works in 1891-92; she was the second Pacific Mail vessel to carry this name. Focus of item: Peru (1892-1919).

priJHK 00144
