Big Creek, Vermilion Dam - Upper end of unlined section of spillway

Description: Big Creek, Vermilion Dam - Upper end of unlined section of spillway - test flow 600 sec. ft. [cubic feet per second]
Type: Visual Materials(Opens in new tab)
Date: July 1956
Call number: photCL SCE 02 - 44646
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
