Big Creek, Vermilion Dam

Description: Big Creek, Vermilion Dam - Considerable undercutting along north bank. Test spill of approx[imately] 600 sec. ft. [cubic feet per second]
Type: Visual Materials(Opens in new tab)
Date: June 1956
Call number: photCL SCE 02 - 44645
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Big Creek, Vermilion Dam
Visual Materials
Big Creek, Vermilion Dam - Flow conditions in channel immediately below radial gate under free flow of 311' head. Theoretical flow approx[imately] 300 sec. ft. [cubic feet per second].
photCL SCE 02 - 44637
Big Creek, Vermilion Dam
Visual Materials
Big Creek, Vermilion Dam - Unlined portion of spillway near upper end under 400 sec. ft. [cubic feet per second] flow. Cat pushing boulders into channel to prevent excessive undercutting.
photCL SCE 02 - 44643
Big Creek, Vermilion Dam - Upper end of unlined section of spillway
Visual Materials
Big Creek, Vermilion Dam - Upper end of unlined section of spillway - test flow 600 sec. ft. [cubic feet per second]
photCL SCE 02 - 44646
Big Creek, Vermilion Dam
Visual Materials
Big Creek, Vermilion Dam - Concrete section of spillway under 600 sec. ft. [cubic feet of water per second, flow]
photCL SCE 02 - 44644
Big Creek, Vermilion Dam - Service spillway
Visual Materials
Big Creek, Vermilion Dam - Service spillway - initial spill of 300 sec. feet. [cubic feet per second]
photCL SCE 02 - 44634
Big Creek, Vermilion Dam - Lower end of service spillway joining Mono Creek
Visual Materials
Big Creek, Vermilion Dam - Lower end of service spillway joining Mono Creek - during initial spill of approximately 300 sec[ond] feet [cubic feet per second]. Compare with 44629
photCL SCE 02 - 44632
