Visual Materials

Big Creek, Vermilion Dam

Description: Big Creek, Vermilion Dam - Slide gate mechanism showing number which indicates degree of gate opening.
Type: Visual Materials(Opens in new tab)
Date: 11/22/1954
Call number: photCL SCE 02 - 44536
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
