Visual Materials
Big Creek, Vermilion Dam
- Description
- Big Creek, Vermilion Dam - Slide gate valve in place in inlet structure.
- Date
- 9/20/1954
- Call number
- photCL SCE 02 - 44494
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108

Visual Materials
Big Creek, Vermilion Dam - Intake works with trash racks in place and water passing through slide gate.
photCL SCE 02 - 44504

Visual Materials
Big Creek, Vermilion Dam - Mono Creek flowing thru inlet structure.
photCL SCE 02 - 44249

Visual Materials
Big Creek, Vermilion Dam - Placing reinforcing steel in inlet structure.
photCL SCE 02 - 44491

Visual Materials
Big Creek, Vermilion Dam - Forms for intake structure and closure section of conduit, also backfill in inlet channel.
photCL SCE 02 - 44204

Visual Materials
Big Creek, Vermilion Dam - Closure section and intake structure showing 3'-0" corrugated bypass, also inlet channel.
photCL SCE 02 - 44206

Visual Materials
Big Creek, Vermilion Dam - Inlet structure - well point system in operation before impervious backfill work.
photCL SCE 02 - 44190
