Visual Materials

Big Creek, Vermilion Dam

Description: Big Creek, Vermilion Dam - Placing forms and reinforcing steel in toe drain outlet structure.
Type: Visual Materials(Opens in new tab)
Date: 9/20/1954
Call number: photCL SCE 02 - 44488
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
