Big Creek, Huntington Lake Dams
Visual Materials
Big Creek, Huntington Lake Dams - [not Huntington Lake - shot is of Dam 7 and Redinger Lake] - View of exposed portion of tunnel intake trash rack.
photCL SCE 02 - 44049
Big Creek, Huntington Lake Dams
Visual Materials
Big Creek, Huntington Lake Dams - [shot is of Dam 7 and Redinger Lake, not Huntington Lake] - Spillway gate piers, note almost perfect condition of concrete.
photCL SCE 02 - 44052
Big Creek, Huntington Lake Dams
Visual Materials
Big Creek, Huntington Lake Dams - [shot is of Dam 7 and Redinger Lake, not Huntington Lake] - Upstream side of spillway gates.
photCL SCE 02 - 44050
Big Creek, Huntington Lake Dams
Visual Materials
Big Creek, Huntington Lake Dams - [not Huntington Lake - shot is of Dam 7 and Redinger Lake] - General view of upstream face taken during draw down to minimum operating level.
photCL SCE 02 - 44048
Big Creek, Huntington Lake Dams
Visual Materials
Big Creek, Huntington Lake Dams - [shot is of Dam 7 and Redinger Lake, not Huntington Lake] - Expansion-contraction joint between blocks 4 & 5, at station 4+21.5, elev. 1355.
photCL SCE 02 - 44051
Big Creek, Huntington Lake Dams - Dam 1 Upstream face
Visual Materials
Big Creek, Huntington Lake Dams - Dam 1 Upstream face - Intake tower and trash rack 9' gate at intake Tunnel #1. Water elevation 6847
photCL SCE 02 - 22808
