Big Creek, Huntington Lake Dams

Description
Big Creek, Huntington Lake Dams - [not Huntington Lake - shot is of Dam 7 and Redinger Lake] - General view of upstream face taken during draw down to minimum operating level.
Type
Visual Materials(Opens in new tab)
Date
3/2/1956
Call number
photCL SCE 02 - 44048
