Portal Powerhouse - Water trapped during night around powerhouse structure

Description
Portal Powerhouse - Water trapped during night around powerhouse structure - due to failure of diversion pipe to carry increased seepage thru rack fill between tunnel diversion channel and bench at elevation.
Type
Visual Materials(Opens in new tab)
Date
9/22/1955
Call number
photCL SCE 02 - 43733
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
