Big Creek, Vermilion Dam

Description: Big Creek, Vermilion Dam - Installing 12" perforated drain [French drain] thru damp area near relief hole R-24. Note sand and gravel aroun pipe.
Type: Visual Materials(Opens in new tab)
Date: 9/14/1955
Call number: photCL SCE 02 - 43702
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
