Portal Powerhouse

Description: Portal Powerhouse - Charging Skip-loader with concrete thru hole in top of 12' pipe, outside tunnel portal.
Type: Visual Materials(Opens in new tab)
Date: 9/3/1955
Call number: photCL SCE 02 - 43693
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
