Big Creek, Vermilion Dam
- Description
- Big Creek, Vermilion Dam - Temp[orary] wier in toe drain channel after storm.
- Date
- 7/21/1955
- Call number
- photCL SCE 02 - 43668
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Big Creek, Vermilion Dam - Downstream channel below toe drain.
photCL SCE 02 - 42971
Visual Materials
Big Creek, Vermilion Dam - Toe drain outlet channel, back water at junction of spillway channel, looking southeast.
photCL SCE 02 - 44715
Visual Materials
Big Creek, Vermilion Dam - Flow of water from spillway channel. Source is a subteranian stream emergency from north side - approximately 15-20 below natural ground & approximately same distance east of toe drain at end of pipe in auxiliary drain #2.
photCL SCE 02 - 44731
Visual Materials
Big Creek, Vermilion Dam - Compacting pervious fill over Toe Drain. Picture from junction of Toe Drain and Intermediate Drain.
photCL SCE 02 - 44317
Visual Materials
Big Creek, Vermilion Dam - First in series of overlapping pictures taken to show the seepage from the east back [bank?] of Old Mono Channel from toe drain outlet weir to point approximately 200' downstream.
photCL SCE 02 - 44822
Visual Materials
Big Creek, Vermilion Dam - Junction of interior drain and toe drain. Spring in center.
photCL SCE 02 - 44287
