Portal Powerhouse

Description: Portal Powerhouse - Diverting tunnel flow from Rancheria Creek channel across main channel and into Potter Creek channel.
Type: Visual Materials(Opens in new tab)
Date: 7/23/1955
Call number: photCL SCE 02 - 43308
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
