Visual Materials

Portal Powerhouse

Description: Portal Powerhouse - Enlarging Potter Creek channel to handle tunnel flow during excavation of tail race channel.
Type: Visual Materials(Opens in new tab)
Date: 7/15/1955
Call number: photCL SCE 02 - 43302
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
