Etiwanda Steam Station - Top of low temperature super heater section

Description: Etiwanda Steam Station - Top of low temperature super heater section - Boiler #2.
Type: Visual Materials(Opens in new tab)
Date: 6/4/1953
Call number: photCL SCE 02 - 43206
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
