Etiwanda Steam Station

Description: Etiwanda Steam Station - Looking north and upward from upper banner platform level. Ends of 1 1/4" water wall tubes in upper left and right. Low temperature superheater inlet headers are at lower edge of picture.
Type: Visual Materials(Opens in new tab)
Date: 7/2/1952
Call number: photCL SCE 02 - 43126
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
