Visual Materials

Kaweah #2 - Flume 1 - Looking upstream from siphon outlet, showing blow-off and valve box. 4" line in foreground is furnishing water for flow 2, 4, 6, & 7 during outage

Description: Kaweah #2 - Flume 1 - Looking upstream from siphon outlet, showing blow-off and valve box. 4" line in foreground is furnishing water for flow 2, 4, 6, & 7 during outage. (Sep. - Dec. 1948)
Type: Visual Materials(Opens in new tab)
Date: 1948
Call number: photCL SCE 02 - 28962
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
