Kaweah #2 - Flume 12 - during erection looking upstream

Description: Kaweah #2 - Flume 12 - during erection looking upstream. (Sep. - Dec. 1948)
Type: Visual Materials(Opens in new tab)
Date: 1948
Call number: photCL SCE 02 - 28959
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
