Visual Materials
Big Creek, Florence Lake Dam
- Description
- Big Creek, Florence Lake Dam - Test Bars on Arch Buttress #49.
- Date
- 3/31/1945
- Call number
- photCL SCE 02 - 26664
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Big Creek, Florence Lake Dam - Test bars on Angle Buttress #25.
photCL SCE 02 - 25363
Visual Materials
Big Creek, Florence Lake Dam - Test bars on top of Angle Buttress #25.
photCL SCE 02 - 25960
Visual Materials
Big Creek, Florence Lake Dam - Mr. T.C. Powers applying sonic test on experimental bars stored on Angle Buttress 25.
photCL SCE 02 - 24749
Visual Materials
Big Creek, Florence Lake Dam - View of Angle Buttress #49, from Arch #49 side.
photCL SCE 02 - 22104
Visual Materials
Big Creek, Florence Lake Dam - View of Angle Buttress #49, from Arch #50 side.
photCL SCE 02 - 22103
Visual Materials
Big Creek, Florence Lake Dam - Closer view of arch and buttress construction in river section, looking west from approximately the upstream face of arch 56. (Intrados forms for Arch 49 and completed footing trench for Arch 50 are shown in background.
photCL SCE 02 - 12767
