Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Repairs to Arch #54 & #52 (spot repairs). [variant of 02-25767a].
Type: Visual Materials(Opens in new tab)
Date: 5/4/1944
Call number: photCL SCE 02 - 25767b
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
