Long Beach Steam Station, Plant #2 - Unit 8-R

Description: Long Beach Steam Station, Plant #2 - Unit 8-R - Construction progress. [Plus two additional shots (#25448: Placing return water box condenser prior to rolling condenser shell into position, & #25449: leveling pads for generator sole plates) on same photocard].
Type: Visual Materials(Opens in new tab)
Date: 7/7/1943
Call number: photCL SCE 02 - 25447
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
