Long Beach Steam Station, Plant #2 - Unit 8-R

Description: Long Beach Steam Station, Plant #2 - Unit 8-R - Generator sole plates & low pressure end of turbine. [Plus additional shot (#25446: Unit 8-R construction progress) on same photocard].
Type: Visual Materials(Opens in new tab)
Date: 7/7/1943
Call number: photCL SCE 02 - 25445
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
