Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Typical progress photo showing placement of gunite in haunches. This particular haunch is between Arches 17 & 18.
Type: Visual Materials(Opens in new tab)
Date: 11/18/1943
Call number: photCL SCE 02 - 24894
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
