Visual Materials

Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Progress photo showing application of 1" reinforced gunite buffer coating along base of Arch #12.
Type: Visual Materials(Opens in new tab)
Date: 5/6/1943
Call number: photCL SCE 02 - 24875
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
