Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - Testing for leaks on Arch 13 with saturated soap solution while steel is subjected to approximately 3/4 lb. air pressure.
Type
Visual Materials(Opens in new tab)
Date
5/8/1943
Call number
photCL SCE 02 - 24877
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
