Visual Materials
Big Creek, Florence Lake Dam
- Description
- Big Creek, Florence Lake Dam - Progress photo showing start of pour in box around east Sluice Gate stem.
- Date
- 12/12/1942
- Call number
- photCL SCE 02 - 24822
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Big Creek, Florence Lake Dam - Progress photo - shooting west sluice gate stem box with gunite.
photCL SCE 02 - 24728
Visual Materials
Big Creek, Florence Lake Dam - Progress photo showing placement of concrete in 4' x 4' culvert portion of east Sluice Gate extension. Bryant crew applying Johns-Manville waterproofing to Arch #52.
photCL SCE 02 - 24819
Visual Materials
Big Creek, Florence Lake Dam - Progress photo showing first stages of backfill west side of channel. Building forms for east Sluice Gate extension and Bryant crew applying asbestile plastic on Arch No. 51.
photCL SCE 02 - 24815
Visual Materials
Big Creek, Florence Lake Dam - Photo showing backfilling in river channel. Building forms for east sluice gate extension.
photCL SCE 02 - 24818
Visual Materials
Big Creek, Florence Lake Dam - Progress photograph showing first guniting on Arch 54. Arch 55 ready for guniting to elevation 7235, and forms nearly complete for first pour in west sluice pipe extension Arch 53.
photCL SCE 02 - 24722
Visual Materials
Big Creek, Florence Lake Dam - [Progress on multiple-arch dam construction, in River Section showing 300' Tower, mixing plant and sluice gate on Arch #53.]
photCL SCE 02 - 12756
