Big Creek, Florence Lake Dam - Intrados Arch #26

Description: Big Creek, Florence Lake Dam - Intrados Arch #26 - Close-up of surface showing Sodium Carbonate efflorescence, Calcium Carbonate deposits, and areas with spalling concrete.
Type: Visual Materials(Opens in new tab)
Date: 3/26/1941
Call number: photCL SCE 02 - 23980
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
