Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Florence Lake Tunnel Intake upstream venturi meter lining.
Type: Visual Materials(Opens in new tab)
Date: 7/9/1940
Call number: photCL SCE 02 - 22988
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
