Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Spurt through open day's work joint 1' from haunch, Buttress #36 in Arch #36, Elevation 7304.
Type: Visual Materials(Opens in new tab)
Date: 11/20/1938
Call number: photCL SCE 02 - 22118
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
