Big Creek, Huntington Lake Dams - Dam #3A

Description: Big Creek, Huntington Lake Dams - Dam #3A - Concreting trench in front of cut-off wall.
Type: Visual Materials(Opens in new tab)
Date: 6/1/1938
Call number: photCL SCE 02 - 23634
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
