Core drill hole

Description: Core drill hole U-13 Upstream face Dam 1 approx. 108 to West of West end of gunnited seam.
Type: Visual Materials(Opens in new tab)
Date: 5/8/1937
Call number: photCL SCE 02 - 20108
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
