Core drill hole upstream face Dam 1

Description
Core drill hole upstream face Dam 1. U-15. Most easterly hole drilled and highest in elevation of any of the 16 holes drilled in the upstream face. Station 3+60.9 Elev. 6630.5.
Type
Visual Materials(Opens in new tab)
Date
5/14/1937
Call number
photCL SCE 02 - 20105
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
