Visual Materials

Santa Ana River #3 Powerhouse

Description: Santa Ana River #3 Powerhouse - Looking downstream on 99 foot truss span [steel frame flume under construction]
Type: Visual Materials(Opens in new tab)
Date: 5/1/1926
Call number: photCL SCE 02 - 11759
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
