Visual Materials
Big Creek Huntington Lake Dams - Dam #3 completed to elev. 6915' with trestle, chutes, drains & reinforcing in place ready to complete dam to elevation 6952.5'. Job H-79#32
photCL SCE 02 - 04732
Visual Materials
Big Creek Huntington Lake Dams - Drilling for reinforcing Dam #2, Huntington Lake. Job H-79#10
photCL SCE 02 - 04713
Visual Materials
Big Creek, Florence Lake Dam - View showing details of shop-built, panel-type extrados forms, and built-in-place intrados forms on Arches 13 &14; also forms for Buttresses 12, 13 &14. [Intrados reinforcing steel has been placed for Arch 13. Buttress head reinforcing also shown for junction between Arches 13-14 and 14-15.]
photCL SCE 02 - 12660
Visual Materials
Big Creek Huntington Lake Dams - Pouring concrete at base of Dam #3, Huntington Lake. Job H-79#9
photCL SCE 02 - 04712
Visual Materials
Big Creek Huntington Lake Dams - Excavation for base of Dam #2. Job H-79#14
photCL SCE 02 - 04717
Visual Materials
Big Creek, Huntington Lake Dams - Dam 1 Upstream face - Approx. stationing 8+00 to 8+50. View showing lower key and reinforcing in place ready for guniting. Lake elevation - 6847
photCL SCE 02 - 22489
