Big Creek, Vermilion Dam - Stream flow

Description: Big Creek, Vermilion Dam - Stream flow - water over top of Intake at 925 [cfs].
Type: Visual Materials(Opens in new tab)
Date: 5/21/1954
Call number: photCL SCE 02 - 44383
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
