Visual Materials

Big Creek, Vermilion Dam

Description: Big Creek, Vermilion Dam - Select impervious backfill in upstream blanket area in former Cold Creek streambed.
Type: Visual Materials(Opens in new tab)
Date: 8/21/1953
Call number: photCL SCE 02 - 44207
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
