Portal Powerhouse

Description: Portal Powerhouse - Ward Tunnel discharge about 200 cfs from State Highway south of Potter Creek Bridge.
Type: Visual Materials(Opens in new tab)
Date: 1/17/1956
Call number: photCL SCE 02 - 43943
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
