Visual Materials

Portal Powerhouse

Description: Portal Powerhouse - Lower end of new diversion after first flow of 400 cfs, during outage to install restriction.
Type: Visual Materials(Opens in new tab)
Date: 11/19/1955
Call number: photCL SCE 02 - 43926
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Portal Powerhouse
Visual Materials
Portal Powerhouse - Up tailrace channel from under bridge, during outage to install triangular restriction at end of branch of penstock.
photCL SCE 02 - 43923
Portal Powerhouse
Visual Materials
Portal Powerhouse - 400 cfs flow from side channel spillway entering tailrace from new diversion.
photCL SCE 02 - 43961
Portal Powerhouse
Visual Materials
Portal Powerhouse - Record pictures of tailrace channel during outage: Upper end of channel and lower end of tunnel diversion channel used during 1955.
photCL SCE 02 - 43798
Portal Powerhouse
Visual Materials
Portal Powerhouse - Attempt to show pattern of outlet, approx. 30% restriction during 1350 cfs flow.
photCL SCE 02 - 43929
Portal Powerhouse
Visual Materials
Portal Powerhouse - Temporary flow diversion from 12' pipe [Ward Tunnel]. Flow about 425 cfs..
photCL SCE 02 - 43643
Portal Powerhouse
Visual Materials
Portal Powerhouse - Temporary flow diversion from 12' pipe [Ward Tunnel]. Flow about 425 cfs..
photCL SCE 02 - 43644
