Huntington Lake, Dam 1

Visual Materials

Huntington Lake, Dam 1

Description: Huntington Lake, Dam 1 - Right angled V-notch weir installed at outlet end of sluice pipe toe of Huntington Lake Dam 1, for measuring total leakage collected from back of steel facing. Zero reading on weir is equivalent to 16 g/m on staff gauge.
Type: Visual Materials(Opens in new tab)
Date: 11/10/1955
Call number: photCL SCE 02 - 43915
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog
