Portal Powerhouse

Description: Portal Powerhouse - Temporary diversion channel on east side of powerhouse. Small left channel carries leakage water from east embankment.
Type: Visual Materials(Opens in new tab)
Date: 9/15/1955
Call number: photCL SCE 02 - 43853
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
