Big Creek, Huntington Lake Dams - Close-up of section of 4" transit half

Description: Big Creek, Huntington Lake Dams - Close-up of section of 4" transit half - tile vertical under-drain fitted to contour of Dam #1.
Type: Visual Materials(Opens in new tab)
Date: 9/28/1955
Call number: photCL SCE 02 - 43747
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
