Visual Materials

Big Creek, Vermilion Dam

Description: Big Creek, Vermilion Dam - Looking north showing erosion on d[own]s[ream face of dam. Taken at approx. sta[tion] 25+00, 400' downstream from toe.
Type: Visual Materials(Opens in new tab)
Date: 7/21/1955
Call number: photCL SCE 02 - 43670
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
