Visual Materials

Big Creek, Huntington Lake Dams

Description: Big Creek, Huntington Lake Dams - Upstream protection chase for top channel at Dam #2 and first two rows of anchor bolts.
Type: Visual Materials(Opens in new tab)
Date: 7/14/1955
Call number: photCL SCE 02 - 43292
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Big Creek, Huntington Lake Dams
Visual Materials
Big Creek, Huntington Lake Dams - Upstream protection closer view of marginal channel at east end of Dam #1, showing anchored in place in 12"x12" cut-off in concrete.
photCL SCE 02 - 43320
Huntington Lake Dams - Upstream protection
Visual Materials
Huntington Lake Dams - Upstream protection - showing pressure exerted against anchor bolts during grouting operation by Prepack Corp.. Note deformation of washer.
photCL SCE 02 - 43537
Big Creek, Huntington Lake Dams - Upstream Protection
Visual Materials
Big Creek, Huntington Lake Dams - Upstream Protection - Tailrace channel upstream from Highway Bridge.
photCL SCE 02 - 43710
Big Creek, Huntington Lake Dams
Visual Materials
Big Creek, Huntington Lake Dams - Upstream Protection showing first upstream fill at east end of Dam #2.
photCL SCE 02 - 43564
Big Creek, Huntington Lake Dams
Visual Materials
Big Creek, Huntington Lake Dams - Upstream Protection another view of first fill along upstream face of Dam #2, at east end.
photCL SCE 02 - 43565
Big Creek, Huntington Lake Dams - Upstream Protection
Visual Materials
Big Creek, Huntington Lake Dams - Upstream Protection - Upstream fill, west section of Dam #2.
photCL SCE 02 - 43711
