Visual Materials

Etiwanda Steam Station

Description: Etiwanda Steam Station - General view of Boiler #1 furnace taken on right hand side. Center wall tubes are on left, rear wall and deflection arch tubes in front, right hand side walls in right.
Type: Visual Materials(Opens in new tab)
Date: 10/6/1952
Call number: photCL SCE 02 - 43145
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
