Big Creek #1 - Bucket changing equipment. General assembly showing reamer and air motor connected up

Description: Big Creek #1 - Bucket changing equipment. General assembly showing reamer and air motor connected up. The reamer is between the two pins set-up as used in opperation on waterwheel, boring bar is included in addition to reamer.
Type: Visual Materials(Opens in new tab)
Date: March 1930
Call number: photCL SCE 02 - 28490
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
