Visual Materials
Big Creek Powerhouse #1 - penstock line #3
You might also be interested in
Big Creek Powerhouse #1 - penstock line #3
Visual Materials
Big Creek Powerhouse #1 - penstock line #3 - proposed relocation between Stations 4+04.17 and 9+42.97 (9+50.49). View looking uphill from point opposite A.P. at 4+04.17. Solid rock or light rubble cover. .
photCL SCE 02 - 26559B
Big Creek Powerhouse #1
Visual Materials
Big Creek Powerhouse #1 - proposed Line #3 Penstock relocation between Stations 4+04.17 and 9+42.97 (9+50.49). View looking toward A.P. at Station 4+04.17 from a point approximately 80 feet up hill.
photCL SCE 02 - 26559D
Big Creek Powerhouse #1
Visual Materials
Big Creek Powerhouse #1 - proposed Line #3 Penstock relocation between Stations 4+04.17 and 9+42.97 (9+50.49). View of steep slope immediately below upper A.P. at Station 4+04.17. Man in picture standing at Angle Point. .
photCL SCE 02 - 26559C
Image not available
Big Creek #1 - Penstock Encasement - Penstock No. 1, Lines 1 & 2
Visual Materials
Big Creek #1 - Penstock Encasement - Penstock No. 1, Lines 1 & 2 - View of Line 3 side of concrete encasement, taken from a point near Line No. 3 Anchor at Station 8+10.
photCL SCE 02 - 26550D
Big Creek, Vermilion Dam
Visual Materials
Big Creek, Vermilion Dam - Looking along center line of service spillway from station 13-00. Axis of dam & centerline of spillway on distant moraine between two trees above man's head.
photCL SCE 02 - 44181
Big Creek Powerhouse #3 - and Penstock line
Visual Materials
Big Creek Powerhouse #3 - and Penstock line - vertical.
photCL SCE 02 - 08852
