Big Creek, Florence Lake Dam - Arch #12

Description: Big Creek, Florence Lake Dam - Arch #12 - Applying Asbestile & special joint fabric.
Type: Visual Materials(Opens in new tab)
Date: 11/14/1942
Call number: photCL SCE 02 - 25583
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
